Specification Basic Information Supported CPU Supports 1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4 Chipset AMD B450 Chipset Form Factor m-ATX Expansion Slots PCI 1 x PCIe 3.0 x16 slot (PCI_E1) – Supports x16 speed with AMD Ryzen 1st and 2nd Generation processors – Supports x8 speed with AMD Ryzen with Radeon Vega Graphics processors – Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors 2 x PCIe 2.0 x1 slots M.2 Socket 1 x M.2 slot (Key M) – Supports PCIe 3.0 x4 (RYZEN Series Processors) or PCIe 3.0 x2 (AMD Athlon with Radeon Vega Graphics) and SATA 6Gb/s – Supports 2242/2260/2280 storage devices Memory Type DDR4 Slots 2 Supported Memory Support DDR4 1866/ 2133/ 2400/ 2667Mhz(by JEDEC) – For AMD Ryzen Gen3 (R5/R7/R9) : – 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE) – For AMD Other CPU – 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE) Dual channel memory architecture Supports ECC UDIMM memory (non-ECC mode) Support non-ECC UDIMM memory Maximum Memory 32GB Graphics Graphics 1 x DVI-D port, supports a maximum resolution of 1920×1200@60Hz 1 x HDMI 1.4 port, supports a maximum resolution of 4096×2160 @24Hz Max Shared Memory 2048 MB Connector & Ports HDMI Yes DVI-D (s) Yes USB (s) 6 x USB 3.2 Gen1 6 x USB 2.0 LAN Port (s) Realtek 8111H Gigabit LAN Supported Storage AMD B450 Chipset : – 4 x SATA 6Gb/s ports – Supports RAID 0, RAID1 and RAID 10 – 1x M.2 slot (Key M) – Supports PCIe 3.0 x4 and SATA 6Gb/s – 1st, 2nd and 3rd Gen AMD Ryzen – Ryzen with Radeon Vega Graphics – 2nd Gen AMD Ryzen with Radeon Graphics – Supports PCIe 3.0 x2 and SATA 6Gb/s – AMD Athlon with Radeon Vega Graphics – A-series – Athlon X4 – Supports 2242/ 2260/ 2280/ 22110 storage devices Audio 8-Channel(7.1) HD Audio with Audio Boost Internal I/O Ports 1x 24-pin ATX main power connector 1x 4-pin ATX 12V power connector 4x SATA 6Gb/s connectors 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x USB 3.2 Gen1 connector (supports additional 2 USB 3.2 Gen1 ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connector 1x Front panel audio connector 2x Front panel connectors 1x Chassis Intrusion connector 1x Serial port connector 1x Clear CMOS jumper TPM (Trusted Platform Module ) 1 x TPM module connector Warranty Information Manufacturing Warranty 03 Years Warranty
